1500 Degree 3.8g/Cm3 Fused Cast AZS Block For Glass Kiln

ZHENGZHOU CAIHUA KILN MASONRY INSTALLATION CO.,LTD
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

1500 Degree 3.8g/Cm3 Fused Cast AZS Block For Glass Kiln

  • 1
  • 2

Brand Name : CH Refractories

Model Number : AZS

Certification : ISO

Place of Origin : China

MOQ : 1 Ton

Price : USD 500-1000 per Ton

Payment Terms : L/C, T/T

Supply Ability : 5000 Ton per month

Delivery Time : 5-15 working days

Packaging Details : Pallet

Name : Glass Kiln Applied Fused Cast AZS Block

Color : White

application : Glass kiln

type : Factory

Contact Now

Glass Kiln Fused Cast AZS Block For Glass Kiln Sell To Global

Glass Kiln Applied Fused Cast AZS Block


AZS-36# Brick is a standard zirconia fused zirconium corundum brick, which has the characteristics of high corrosion resistance and low pollution resistance of glass liquid, and the performance in these two aspects is balanced. The fused cast AZS brick is suitable for the parts in the glass furnace which are in direct contact with the glass liquid, such as the wall brick of the melting pool, the paving brick, the feeding port and so on.
AZS-41# brick is very high-grade zirconia fused zirconium corundum brick, it has very high corrosion resistance of glass liquid and outstanding low pollution to glass liquid. It is suitable for the parts with high corrosion resistance in glass kiln, such as full electric furnace, fluid hole, kiln, bubble brick, brick at the corner of feeding, etc.

Applications of Zirconia Corundum(AZS) Brick:
Widely be used for linings of furnace in glass industries.

Items Unit Index
AZS33-Y AZS36-Y AZS41-Y
Chemical composition Al2O3 % ≤50 ≤42 ≤40
ZrO2 % 32-36 35-40 40-44
1650 SiO2 % ≤16 ≤14 ≤13
Na2O % ≤1.45 ≤1.45 ≤1.3
Fe2O3+TiO2+CaO+MgO+Na2O+K2O % ≤2 ≤2 ≤2
Fe2O3+TiO2 % ≤0.3 ≤0.3 ≤0.3
Bulk density g/cm3 ≥3.75 ≥3.8 ≥3.95
Apparent porosity % ≤1.5 ≤1 ≤1
Static anti-corrosion rate of glass liquid(ordinary soda-lime glass, 1500℃*36h) Mm/24h ≤1.5 ≤1.4 ≤1.3
Initial exudation temperature of glass phase ≥1400 ≥1400 ≥1400
Bubble release proportion (ordinary soda-lime glass, 1300℃*10h) % ≤2 ≤1.5 ≤1
Glass phase seepage discharge(1500℃*4h) % ≤2 ≤3 ≤3
Working temperature ≥1650 ≥1650 ≥1650

Advantages of CH series Glass Kiln Applied Fused Cast AZS Block:
Erosion resistance. Ultra low apparent porosity
High strength and high compression resistance
Thermal shock resistance and erosion resistance
Performance in high temperature, good thermal conductivity
Free sampleFree construction guidance free 3D design
Customerize mould according to different size requirements for free
Caihua refractory company manufactured azs bricks with very competitive price comparing with other suppliers in China.
